Glass Four Edge Grinding Machine

  • Home
  • Products
  • Glass Four Edge Grinding Machine
  • Glass Four Edge Grinding Machine (Three Heads)
Glass Four Edge Grinding Machine

Horizontal 4-Edge Glass Grinder for Smooth Glass Edge Processing

Three Grinding Heads

Yalong offers 4-edge horizontal glass grinding machine on which you can process four edges of the glass at the same time. The auto control system allows to automatically grind the glass according to its thickness. This glass grinding machine can deal with flat glass with size of 350*700mm~1600*3600mm and with thickness of 4~10mm. Yalong is dedicated to providing high-efficiency, high-precision and energy-saving glass edge grinding solutions.

Request a Quote
Specifications
Model Max. Glass Min. Glass Glass Thickness Working Speed
YL-SM25-03 2500*3600mm 350*700mm 4-10mm 0-25m/min
YL-SM16-03 1600*2500mm 350*700mm 4-10mm 0-25m/min
Features
    1. High efficiency
    2. 1. Three beams and three grinding heads enable to perform chamfering on the four edges of glass
    1. Simple operations
    2. 1. HMI servo control system
      2. Auto detection of the glass size, thickness and position. Auto processing.
    1. Energy saving
    2. 1. Variable-frequency control and automatic induction of glass feeding. Energy saving mode will turn on if there is no glass input within 60s.
    1. Application Versatility
    2. 1. Our glass four edge grinding machine is suitable for chamfering four edges of rectangle glass sheet, and performing glass washing.
      2. It is an ideal glass machine used for processing architectural glass, insulating glass, doors and windows.
Get in Touch

If you have questions about our products or want to request a quotation, please feel free to contact us at any time.

As a glass processing machinery manufacturer, Yalong mainly focuses on developing and manufacturing glass washing and glass grinding machines that are made to fit different glass fabrication applications. We do not only provide glass manufacturers and glass processing facilities with glass machinery, but also support worldwide customers in the field of glass working to enhance their glass production efficiency, product quality and energy saving. Thanks to our long period of engagement in the glass processing industry, we acquired professional expertise and in-depth knowledge to provide the precise glass processing solution for your glass production application. No matter whether your need is glass washing or glass grinding, Yalong can help you select the appropriate glass processing equipment that well suits your glass manufacturing needs.
